Stock #
966733905
HUSQVARNA 565
In Stock
Call for Price
Authorized Parts & Service Depot for John Deere, STIHL, Husqvarna & More. Locally Owned Business. 4,000 sq. ft. of Showroom
Overview
Specifications
features
engine
emission
equipment
dimensions
lubricant
sound and noise
vibration
literature
Videos
Documents
Product DescriptionWith outstanding cutting performance, the 565 will help you work faster even with long guide bars. Excellent cooling capacity and state-of-the art filtration means great performance and easy operation even for the toughest jobs. Equipped with AutoTune™ and Air Injection™ and with low vibration levels, the 565 is a powerful yet ergonomically designed chainsaw for fast, safe work. |
Model
565
Category Name
CHAINSAWS & FORESTRY TOOLS
Year
2023
Sale Type
New
Manufacturer
Husqvarna
Features
Better chip ejection avoids cloggingThe clutch cover is designed to optimise rapid, safe saw chip ejection. Prevents clogging, even when cutting long fibre wood. |
Better manoeuvrability gives full controlThe front handle bar position is close to the center of gravity, giving you better cutting control. |
10 times quicker air/fuel mix adjustmentAutoTune™ ensures a correctly tuned engine setting and optimised engine performance in all conditions. |
Low vibrationsHusqvarna’s anti vibration system efficiently separates your hands from the vibrations generated by the engine and the cutting equipment. This is to protect your body but also to reduce the fatigue in your arms and hands and in the end of the day contribute to make your workday more productive. |
Soft cut-out systemThe innovative system for engine control is designed for providing a long engine life. The system monitors the engine and assures that the engine always is protected from over-revving. |
Fuel IndicatorTransparent fuel indicator makes it easy to check fuel level |
Felling sight to last a lifetimePerfect sight is critical when felling – so we made one that will outlast the chainsaw itself. |
|
|
Magnesium crankcaseSturdily built crankcase withstands high rpms and tough professional use, ensuring a long service life. |
Powerful and Efficient X-TORQ® EnginePowerful X-TORQ® engine reduces emissions by up to 60% and increases fuel efficiency by up to 20%
|
Spark Plug
NGK CMR6H
Idling Speed
2,700 rpm
Power Output
3.7 kW
Torque, Max.
4.2 Nm
Electrode Gap
0.5 mm
Oil Pump Type
Adjustable flow, no flow at idle
Fuel Consumption
442 g/kWh
Maximum Power Speed
9,300 rpm
Torque, Max. At Rpm
6,900 rpm
Cylinder Displacement
70.6 cm³
Ignition Module Air Gap
0.3 mm
Clutch Engagement Speed (±120)
3,800 rpm
Maximum Recommended Engine Speed
13,500 rpm
Exhaust Emissions (CO2 EU V)
804 g/kWh
Gauge
1.3 mm
Pitch
3/8"
Chain Type
C83
Sprocket Type
Rim 7
Bar Length (inch)
16 in
Recommended Bar Length, Max
70 cm
Recommended Bar Length, Min
38 cm
Weight (excl. Cutting Equipment)
6.5 kg
Oil Tank Volume
0.7 US pint
Lubricant Type (Engine)
Husqvarna 2 stroke or equiv. at 50:1
Sound Power Level, Measured
117 dB(A)
Sound Power Level, Guaranteed (LWA)
119 dB(A)
Sound Pressure Level At Operators Ear
105 dB(A)
Equivalent Vibration Level (ahv, Eq) Rear Handle
5.3 m/s²
Equivalent Vibration Level (ahv, Eq) Front Handle
5.2 m/s²
Literature
| Name | Link |
|
Owner manuals |
Download |
Videos
Documents
Model
565
Category Name
CHAINSAWS & FORESTRY TOOLS
Year
2023
Sale Type
New
Manufacturer
Husqvarna
Quantity
1
